Lord of Robots

LoR Core Version 3

LoR Core Version 3

Regular price $45.00 CAD
Regular price Sale price $45.00 CAD
Sale Sold out

The LoR Core V3 is an embedded robot controller and the main controller used for the the Lord of Robots' MiniBot platform, built on the ESP32 and programmed using the Arduino environment. Developed by Lord of Robots, it powers every MiniBot and is supported by a custom Arduino library to make it easy for builders to create, control, and customize their robots.

Technical Specifications:

  • Power input: 6-12 VDC (2S-3S)
  • IO Port: 12 GPIO (RC Servo style, signal/V+/GND)
  • Selectable V+ output: 6VDC (Default)/5VDC/3.3VDC
  • AUX Port: I2C, SPI, UART, or 8 GPIO
  • 4 user definable buttons / 1 user definable switch
  • WIFI and Bluetooth
  • 4 addressable RGB LEDs
  • USB C programing
  • Size: 50mm x 50mm x 15mm
  • Weight: 20g

Data Sheet: CLICK HERE



View full details
